Laser Machine 1200W 019

At Bos Lock, we supply Laser Machine 1200W 019 to enterprises, power companies, railway companies, and communication companies, appropriate for clearing high altitude obstructions!
Questions? Contact us. This is a custom product and will take 2-8 days to ship.
Laser obstacle-clearing device is a device that uses high-energy laser technology to realize non-contact obstacle-clearing, It is mostly used for removing foreign objects suspended at high altitude in industries such as power systems, railways and communications
Principle of operation:
It is based on near infrared laser technology. Electrical energy is converted to high density light energy through fiber optic communication. The laser is of wavelength 1080nm, peak wavelength 532nm and concentrated spot size 5mm@100m, 3mm@50m It can instantaneously produce high temperatures above 3000 ℃, which can cause the rapid melting or flaking of nonmetallic foreign items from the ice layers via thermal expansion effects.

Advantages of the product-Non contact operation:

No need to ascend or switch off power, reduce fall from high altitude, electric shock, etc. risk, appropriate for cases such as high voltage transmission line, railway contact network.
-High efficiency: Single person operation may finish the barrier clearing in a short time. For example, Southern Power Grid’s fifth generation laser obstacle clearing technology can clear a tree obstruction in less than 10 minutes, while traditional manual obstacle removal takes at least 2 hours.
-Accurate and safe: It can accurately cut foreign things without damaging the circuit body and has many safety protection features such as human body sensing devices and anti-tilting capabilities.
– Wide adaptability: can work in the environment of -20 ℃ ~ 50 ℃, resistance to the interference of level 6 wind, and can remove foreign items such as kite strings, plastic films, tree branches and ice.

Laser Machine 1200W 019 | Buy 1200 watt laser

Application scenarios-Power industry: Clearance of floating objects, tree obstacles, etc., on transmission lines to prevent short circuit tripping.
Railway system: Rapidly clear foreign items such as tunnel ice from the contact network to maintain the continuity of train power supply.- Emergency rescue: Quickly resume power and transportation after typhoons, ice, and snow disasters.
Functional aspects of the equipment
Night vision low light
Foreign Object Intrusion Alert (FOIA)
Fingerprint Verification for Password Login
GPS-positioning
Smart focused adjustment
Automatic cut electronic fence
Emergency halt
Smart distance measuring
Parameters of equipment
Laser power 1200w
Laser wavelength 1080+/-1nm
Spot size < 150m @ 15mm lens
Operating distance 0-500m
Laser power supply voltage DC39-54.6V
DC39-54.6V Lithium Battery Output
Wireless Control Mode
Air cooling Cooling system
30x zoom on the camera
5-600 meters laser ranging
Overall chassis size: 800*550*330mm
Main chassis weight 45kg.
Launch head dimensions: 560 x 355 x 225 mm
Launch head weight 5 kg Battery weight 20Kg
